技术规范:
1.公称压⼒: PN≤1.6MPa
2.⼯作介质: ⽔、⾮腐蚀性液体
3.⼯作温度: 0℃≤t≤110℃
4.管螺纹符合IS0 228标准(GB/T7307)
技术规范:
1.公称压⼒: PN≤1.6MPa
2.⼯作介质: ⽔、⾮腐蚀性液体
3.⼯作温度: 0℃≤t≤110℃
4.管螺纹符合IS0 228标准(GB/T7307)
| 规格 | L | A | H |
| 25x1620-2 | 1-48 | 100 | 325 |
| 25x1620-3 | 2-48 | 148 | 325 |
| 25x1620-4 | 3-48 | 196 | 325 |
| 25x1620-5 | 4-48 | 244 | 325 |
| 25x1620-6 | 5-48 | 292 | 325 |
| 25x1620-7 | 6-48 | 340 | 325 |
| 25x1620-8 | 7-48 | 388 | 325 |
| 规格 | L | A | H |
| 32x1620-2 | 1-48 | 100 | 325 |
| 32x1620-3 | 2-48 | 148 | 325 |
| 32x1620-4 | 3-48 | 196 | 325 |
| 32x1620-5 | 4-48 | 244 | 325 |
| 32x1620-6 | 5-48 | 292 | 325 |
| 32x1620-7 | 6-48 | 340 | 325 |
| 32x1620-8 | 7-48 | 388 | 325 |
